PRODUCT INFORMATION
WONCOSA NON-DESTRUCTIVE REAL TIME
X-RAY INSPECTION SYSTEM
SPECIFICATION
Micro
Focus Series
| |
MFS-4080 |
MFS-4090 |
MFS-4100 |
MFS-4130 |
|
X-RAY GENERATOR
|
TUBE VOLTAGE |
80KVP |
90KVP |
100KVP |
130KVP |
|
TUBE CURRENT |
100m
A |
8w |
100m
A |
300m
A |
|
FOCUS SIZE |
6x8m
m |
7m
m |
5m
m |
10X10m
m |
|
COOLING |
AIR COOLING |
|
X-RAY TUBE AGING |
AUTO |
MANUAL |
AUTO |
AUTO |
|
X-RAY DETECTOR
|
I.I. CAMERA |
2 INCH / 4 INCH |
|
TV MONITOR |
12 INCH B/W |
| SAMPLE
TABLE |
Z-AXIS |
700mm |
|
X-AXIS |
300mm |
|
Y-AXIS |
300mm |
|
MAGNIFICATION |
MAX. 400 TIMES |
|
IRRADIATION BOX X-RAY LEAKAGE |
1 m
sv/ H |
|
SAMPLE WINDOW |
Ö
|
|
INTERLOCK |
Ö
|
|
LASER SPOT LIGHT |
Ö
|
|
IMAGE PROCESSOR |
IMAGE S
III |
|
VIDEO PRINTER |
SONY UP-895 |
|
SYSTEM CONFIGURATION |
SEPARATED TYPE |
|
POWER SOURCE |
AC 100V / 220V / 240V 50/60Hz |
|
DIMENSIONS
|
CONTROL UNIT |
600 (W) / 900 (D) / 550 (H) mm |
|
MAIN UNIT |
1000 (W) / 1200 (D) / 1950 (H) mm |

Compax Series
| |
COMPAX 100 |
COMPAX 125 |
COMPAX 150 |
|
INPUT |
AC 100V / 220V / 240V 50Hz/60Hz |
|
TUBE MAX. OUTPUT |
100KVP |
125KVP |
150KVP |
|
TUBE MAX CURRENT |
3mA CONTINOUS |
|
FOCUS SIZE |
0.4 X 0.4mm |
0.3 X 0.3mm |
|
POWER CONSUMPTION |
1 KW
|
|
COOLING METHOD |
AIR COOLING OIL CIRCULATING |
AIR COOLING |
|
X-RAY LEAKAGE |
UNDER 1m
SV |
|
X-RAY TV CAMERA |
LONG LIFE VIDCON CAMERA SYSTEM |
|
SCANNING LINE |
1 LINES 50/60Hz 2:1 INTERASE |
|
RESOLUTION |
OVER 25m
m |
|
X-RAY PHOTO-TUBE |
VIDICOM TUBE |
|
TV MONITOR |
12" HIGH RESOLUTION B/W MONITOR |
|
SAMPLE TABLE:
|
X-AXIS |
300 mm
|
| Y-AXIS |
300 mm
|
|
IMAGE PROCESSOR |
IMAGE S
- III |
|
VIDEO COPY |
SONY UP-895 |
